PSA Nitrogen Generator System 99% Purity 5-5500Nm3/hr
商品の詳細:
| Place of Origin: | China |
| ブランド名: | KERONG GAS |
| 証明: | ISO9001, CE, ASME |
| Model Number: | KRN |
お支払配送条件:
| Minimum Order Quantity: | 1 pc |
|---|---|
| 価格: | negotiable |
| Packaging Details: | Wooden box |
| Delivery Time: | 8 weeks |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000pcs per year |
|
詳細情報 |
|||
| Name: | Nitrogen Generation System Package | Purity: | 90%~99.9999% |
|---|---|---|---|
| Dew point: | -45℃ or more | Material: | Stainless steel or carbon steel |
| Capacity: | 5Nm3/hr~5500Nm3/hr | Pressure: | Adjustable |
| ハイライト: | high efficiency PSA nitrogen generator,99% gas purity nitrogen system,industrial nitrogen generation package |
||
製品の説明
| Attribute | Value |
|---|---|
| Name | Nitrogen Generation System Package |
| Purity | 90%~99.9999% |
| Dew point | -45℃ or more |
| Material | Stainless steel or carbon steel |
| Capacity | 5Nm3/hr~5500Nm3/hr |
| Pressure | Adjustable |
Our High Efficiency 99% Gas Purity Nitrogen Generation System Package is designed for continuous, on-site nitrogen production with optimal energy savings. Delivering 99% purity, it meets the needs of industries such as food packaging, electronics, metal processing, and chemical manufacturing.
Utilizing advanced Pressure Swing Adsorption (PSA) or membrane separation technology, the system integrates an air compressor, dryer, filtration, and automated controls into a compact, easy-to-install package. Engineered for low operating costs, stable performance, and minimal maintenance, it eliminates reliance on nitrogen cylinders. This solution ensures a consistent nitrogen supply while maximizing productivity and efficiency in demanding industrial applications.
| Model | Nitrogen flow rate (Nm3/hr) | Purity (%) | Air need (m3/min) | Net dimensions (mm) |
|---|---|---|---|---|
| KRN159 | 7 | 99 | 0.33 | 1200*600*1900 |
| 6 | 99.5 | 0.32 | ||
| 5 | 99.9 | 0.32 | ||
| 4 | 99.95 | 0.3 | ||
| 3 | 99.99 | 0.25 | ||
| 2 | 99.999 | 0.22 |
Note: Complete technical specifications available upon request.
- Online monitoring of oxygen purity, pressure, flow rate and dew point
- Unqualified oxygen sound and light alarm, long time alarm automatic stop, unqualified automatic oxygen emptying
- Air dryer and air filters automatic drainer discharge
- Automatic warning of spare parts replacement
- Remote control / fully automatic operation
- Molecular sieve automatic compaction
- Pneumatic valve switching by programmable controller automatic control
- The IPC, DCS, the specific configuration of other specific programs
