SABER Certified PSA Nitrogen Generator for Laser Cutting 5-5500Nm3/hr
商品の詳細:
| Place of Origin: | China |
| ブランド名: | KERONG GAS |
| 証明: | ISO9001, CE, ASME |
| Model Number: | KRN |
お支払配送条件:
| Minimum Order Quantity: | 1 pc |
|---|---|
| 価格: | negotiable |
| Packaging Details: | Wooden box |
| Delivery Time: | 8 weeks |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000pcs per year |
|
詳細情報 |
|||
| Name: | Nitrogen Generator For Laser Cutting | Purity: | 90%~99.9999% |
|---|---|---|---|
| Dew point: | -45℃ or more | Material: | Stainless steel or carbon steel |
| Capacity: | 5Nm3/hr~5500Nm3/hr | Pressure: | Adjustable |
| ハイライト: | SABER certified nitrogen generator,PSA nitrogen generator for laser cutting,nitrogen gas generator with 10-year warranty |
||
製品の説明
| Attribute | Value |
|---|---|
| Name | Nitrogen Generator For Laser Cutting |
| Purity | 90%~99.9999% |
| Dew point | -45℃ or more |
| Material | Stainless steel or carbon steel |
| Capacity | 5Nm3/hr~5500Nm3/hr |
| Pressure | Adjustable |
Our SABER Certified Nitrogen Generator for Laser Cutting is built with a 10-year design lifetime, ensuring long-term reliability and performance. Certified under the SABER conformity system, it meets Saudi Arabian industrial safety and quality standards.
Using advanced Pressure Swing Adsorption (PSA) or membrane separation technology, it delivers continuous, high-purity nitrogen (up to 99.99%) directly to your laser cutting system, guaranteeing clean, oxidation-free cuts. Its durable construction and premium components reduce wear, extending operational life while maintaining efficiency.
With automatic controls, low maintenance requirements, and energy-saving design, it offers a cost-effective, dependable nitrogen supply for high-demand laser cutting operations.
Capacity: 5-5500Nm³/h
Dew point: -45 ℃ or more
Purity: 90%~99.9999%
| Model | Nitrogen flow rate(Nm3/hr) | Purity(%) | Air need(m3/min) | Net dimensions(mm) |
|---|---|---|---|---|
| KRN159 | 7 | 99 | 0.33 | 1200*600*1900 |
| 6 | 99.5 | 0.32 | ||
| 5 | 99.9 | 0.32 | ||
| 4 | 99.95 | 0.3 | ||
| 3 | 99.99 | 0.25 | ||
| 2 | 99.999 | 0.22 |
- Online monitoring of oxygen purity, pressure, flow rate and dew point.
- Unqualified oxygen sound and light alarm, long time alarm automatic stop, unqualified automatic oxygen emptying.
- Air dryer and air filters automatic drainer discharge.
- Automatic warning of spare parts replacement.
- Remote control / fully automatic
- Molecular sieve automatic compaction
- Pneumatic valve switching by programmable controller automatic control
- The IPC, DCS, the specific configuration of other specific programs
